T9ES5D12-24
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy T9ES5D12-24 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy T9ES5D12-24 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | T9ES5D12-24 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | RELAY GEN PURPOSE SPDT 20A 24V |
| Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Reference Price (In US Dollars) | 500 pcs | ||||
|---|---|---|---|---|---|
| $1.211 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | T9ES5D12-24 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPDT 20A 24V | Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Quantity Available | 29139 pcs | Data sheet | T9E Series Datasheet |
| Category | Relays | Turn On Voltage (Max) | 18 VDC |
| Turn Off Voltage (Min) | 2.4 VDC | Termination Style | PC Pin |
| Switching Voltage | 250VAC - Max | Series | T9E |
| Release Time | 15ms | Relay Type | General Purpose |
| Packaging | Bulk | Other Names | 2027234-4 PB1841 T9ES5D12-24-ND |
| Operating Temperature | -40°C ~ 85°C | Operate Time | 15ms |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 29 Weeks | Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Features | Insulation - Class F, Sealed - Fully | Detailed Description | General Purpose Relay SPDT (1 Form C) 24VDC Coil Through Hole |
| Contact Rating (Current) | 20A | Contact Material | Silver Tin Oxide Indium Oxide (AgSnOInO) |
| Contact Form | SPDT (1 Form C) | Coil Voltage | 24VDC |
| Coil Type | Non Latching | Coil Resistance | 576 Ohms |
| Coil Power | 1 W | Coil Current | 41.7mA |
