808-AG11D
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 808-AG11D with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 808-AG11D with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 808-AG11D |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN IC DIP SOCKET 8POS GOLD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 60 pcs | 120 pcs |
|---|---|---|---|---|---|
| $0.957 | $0.87 | $0.817 | $0.781 | $0.745 | |
| 300 pcs | 540 pcs | 1020 pcs | 2520 pcs | ||
| $0.674 | $0.621 | $0.532 | $0.497 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 808-AG11D | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN IC DIP SOCKET 8POS GOLD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 63629 pcs | Data sheet | Dip Sockets Reference Guide1437539-2 Drawing |
| Category | Connectors, Interconnects | Type | DIP, 0.3" (7.62mm) Row Spacing |
| Termination Post Length | 0.125" (3.18mm) | Termination | Solder |
| Series | 800 | Pitch - Post | 0.100" (2.54mm) |
| Pitch - Mating | 0.100" (2.54mm) | Packaging | Tube |
| Other Names | 1437537-8 808-AG11D-ND A126552 |
Operating Temperature | -55°C ~ 105°C |
| Number of Positions or Pins (Grid) | 8 (2 x 4) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 8 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Material | Polyester | Features | Open Frame |
| Contact Resistance | 10 mOhm | Contact Material - Post | Copper Alloy |
| Contact Material - Mating | Copper Alloy | Contact Finish Thickness - Post | 80.0µin (2.03µm) |
| Contact Finish Thickness - Mating | 25.0µin (0.63µm) | Contact Finish - Post | Tin-Lead |
| Contact Finish - Mating | Gold |
