Home > Products > Connectors, Interconnects > Rectangular Connectors - Headers, Male Pins > 102570-5

102570-5

102570-5
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 102570-5 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number 102570-5
Manufacturer Agastat Relays / TE Connectivity
Description CONN HEADER R/A .100 14POS 15AU
Lead Free Status / RoHS Status Contains lead / RoHS non-compliant
In Stock 66527 pcs
Reference Price
(In US Dollars)		1344 pcs
$0.538

Submit a Request For Quotation on quantities greater than those displayed.

Target Price:(USD)
Quantity:
Total:
$0.538

Product parameter

Part Number 102570-5 Manufacturer Agastat Relays / TE Connectivity
Description CONN HEADER R/A .100 14POS 15AU Lead Free Status / RoHS Status Contains lead / RoHS non-compliant
Quantity Available 66527 pcs Data sheet 102570
Category Connectors, Interconnects Voltage Rating -
Termination Solder Style Board to Board or Cable
Shrouding Shrouded - 4 Wall Series AMPMODU Mod II
Row Spacing - Mating 0.100" (2.54mm) Pitch - Mating 0.100" (2.54mm)
Packaging Tray Overall Contact Length -
Other Names A26802 Operating Temperature -65°C ~ 105°C
Number of Rows 2 Number of Positions Loaded All
Number of Positions 14 Mounting Type Through Hole, Right Angle
Moisture Sensitivity Level (MSL) 1 (Unlimited) Material Flammability Rating UL94 V-0
Mated Stacking Heights - Manufacturer Standard Lead Time 21 Weeks
Lead Free Status / RoHS Status Contains lead / RoHS non-compliant Insulation Material Thermoplastic
Insulation Height 0.400" (10.16mm) Insulation Color Black
Ingress Protection - Features -
Fastening Type Detent Lock Detailed Description Connector Header Through Hole, Right Angle 14 position 0.100" (2.54mm)
Current Rating 3A Contact Type Male Pin
Contact Shape Square Contact Material Phosphor Bronze
Contact Length - Post 0.135" (3.43mm) Contact Length - Mating 0.318" (8.08mm)
Contact Finish Thickness - Post 100.0µin (2.54µm) Contact Finish Thickness - Mating 15.0µin (0.38µm)
Contact Finish - Post Tin-Lead Contact Finish - Mating Gold
Connector Type Header Applications -
