Home > Products > Connectors, Interconnects > Terminals - Spade Connectors > 1-322249-0

1-322249-0

1-322249-0
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1-322249-0 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number 1-322249-0
Manufacturer Agastat Relays / TE Connectivity
Description CONN SPADE TERM 16-22AWG #8 RED
Lead Free Status / RoHS Status Lead free / RoHS Compliant
In Stock 253712 pcs
Reference Price
(In US Dollars)		1 pcs10 pcs25 pcs50 pcs100 pcs
$0.193$0.182$0.163$0.145$0.139
250 pcs500 pcs1000 pcs2500 pcs
$0.127$0.121$0.10$0.091

Submit a Request For Quotation on quantities greater than those displayed.

Target Price:(USD)
Quantity:
Total:
$0.193

Product parameter

Part Number 1-322249-0 Manufacturer Agastat Relays / TE Connectivity
Description CONN SPADE TERM 16-22AWG #8 RED Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 253712 pcs Data sheet 322249
Category Connectors, Interconnects Wire Gauge 16-22 AWG
Width - Outer Edges 0.296" (7.52mm) Tongue Inside Opening 0.171" (4.34mm)
Termination Crimp Terminal Type Flanged
Stud/Tab Size 8 Stud Series Plasti-Grip
Packaging Bulk Other Names 1-322249-0-ND
13222490
A27433
Mounting Type Free Hanging (In-Line) Moisture Sensitivity Level (MSL) 1 (Unlimited)
Material - Insulation Poly-Vinyl Chloride (PVC) Manufacturer Standard Lead Time 14 Weeks
Length - Termination 0.416" (10.57mm) Length - Ring Center to Termination 0.203" (5.16mm)
Length - Overall 0.780" (19.81mm) Lead Free Status / RoHS Status Lead free / RoHS Compliant
Insulation Diameter 0.105" ~ 0.140" (2.67mm ~ 3.56mm) Insulation Insulated
Features Serrated Termination Detailed Description Red 8 Stud Spade Terminal Connector Crimp 16-22 AWG
Contact Material Copper Contact Finish Tin
Color Red

This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
