Home > Products > Discrete Semiconductor Products > Transistors - Bipolar (BJT) - Single > 2SC3902T

2SC3902T

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2SC3902T with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	2SC3902T
Manufacturer	AMI Semiconductor / ON Semiconductor
Description	TRANS NPN 160V 1.5A TO126ML
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 5985 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	2SC3902T	Manufacturer	AMI Semiconductor / ON Semiconductor
Description	TRANS NPN 160V 1.5A TO126ML	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	5985 pcs	Data sheet	2SA1507, 2SC3902
Category	Discrete Semiconductor Products	Voltage - Collector Emitter Breakdown (Max)	160V
Vce Saturation (Max) @ Ib, Ic	450mV @ 50mA, 500mA	Transistor Type	NPN
Supplier Device Package	TO-126ML	Series	-
Power - Max	1.5W	Packaging	Bulk
Package / Case	TO-225AA, TO-126-3	Other Names	2SC3902T-ND 2SC3902TOS
Operating Temperature	150°C (TJ)	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Frequency - Transition	120MHz	Detailed Description	Bipolar (BJT) Transistor NPN 160V 1.5A 120MHz 1.5W Through Hole TO-126ML
DC Current Gain (hFE) (Min) @ Ic, Vce	100 @ 100mA, 5V	Current - Collector Cutoff (Max)	1µA (ICBO)
Current - Collector (Ic) (Max)	1.5A

This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
