DC2422A-B
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DC2422A-B with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DC2422A-B with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DC2422A-B |
|---|---|
| Manufacturer | ADI (Analog Devices, Inc.) |
| Description | DEMO BOARD FOR LTC7812EUH |
| Lead Free Status / RoHS Status | Not applicable / Not applicable |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $73.188 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | DC2422A-B | Manufacturer | ADI (Analog Devices, Inc.) |
|---|---|---|---|
| Description | DEMO BOARD FOR LTC7812EUH | Lead Free Status / RoHS Status | Not applicable / Not applicable |
| Quantity Available | 420 pcs | Data sheet | LTC7812 DatasheetDC2422A Demo Manual |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 10 V ~ 16 V |
| Voltage - Input | 4 V ~ 36 V | Utilized IC / Part | LTC7812 |
| Supplied Contents | Board(s) | Series | - |
| Regulator Topology | Boost, Buck | Outputs and Type | 1, Non-Isolated |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 8 Weeks |
| Main Purpose | DC/DC, Step Up or Down | Lead Free Status / RoHS Status | Not applicable / Not applicable |
| Frequency - Switching | - | Detailed Description | LTC7812 - DC/DC, Step Up or Down 1, Non-Isolated Outputs Evaluation Board |
| Current - Output | 8A | Board Type | Fully Populated |
| Base Part Number | LTC7812 |
