158214-0120-HF625/14-D-3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 158214-0120-HF625/14-D-3 with confidence from Components-World.HK, 1 Year Warranty
Dowload 158214-0120-HF625/14-D-3 Details in PDFSee Product Specifications for product details.
Buy 158214-0120-HF625/14-D-3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 158214-0120-HF625/14-D-3 |
|---|---|
| Manufacturer | 3M |
| Description | DBL END CBL ASY 14POS SKT 3" |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | 250 pcs |
|---|---|---|---|---|---|
| $2.274 | $2.184 | $1.911 | $1.82 | $1.593 | |
| 500 pcs | 1000 pcs | 2500 pcs | 5000 pcs | ||
| $1.547 | $1.32 | $1.229 | $1.183 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 158214-0120-HF625/14-D-3 | Manufacturer | 3M |
|---|---|---|---|
| Description | DBL END CBL ASY 14POS SKT 3" | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 28081 pcs | Data sheet | HF625 Series Datasheet158 Series DrawingCustom Cable Part Number BreakdownRibbon Cable Assembly Length Guide |
| Category | Cable Assemblies | Usage | - |
| Shielding | Unshielded | Series | - |
| Pitch - Connector | 0.079" (2.00mm) | Pitch - Cable | 0.039" (1.00mm) |
| Other Names | 3M156021-HF14S-3M156021-3 HW-RIBBON14-3M-3 |
Number of Rows | 2 |
| Number of Positions | 14 | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Length | 0.250' (76.20mm, 3.00") | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | - | Detailed Description | 14 Position Cable Assembly Rectangular Socket to Socket 0.250' (76.20mm, 3.00") |
| Contact Finish Thickness | 30.0µin (0.76µm) | Contact Finish | Gold |
| Connector Type | Socket to Socket | Color | Gray, Ribbon |
| Cable Termination | IDC |
