PXCM0324WD15A
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PXCM0324WD15A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PXCM0324WD15A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PXCM0324WD15A |
|---|---|
| Manufacturer | TDK-Lambda Americas, Inc. |
| Description | DC DC CONVERTER +/-15V 3W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | |||
|---|---|---|---|---|---|
| $19.765 | $18.513 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | PXCM0324WD15A | Manufacturer | TDK-Lambda Americas, Inc. |
|---|---|---|---|
| Description | DC DC CONVERTER +/-15V 3W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2018 pcs | Data sheet | PXC-M03 Series Datasheet |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -15V | Voltage - Output 1 | 15V |
| Voltage - Isolation | 5kV | Voltage - Input (Min) | 9V |
| Voltage - Input (Max) | 36V | Type | Isolated Module |
| Size / Dimension | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) | Series | PXC-M03 |
| Power (Watts) | 3W | Packaging | Tube |
| Package / Case | 24-DIP Module, 6 Leads | Other Names | 285-2389 PXC-M03-24WD15-A |
| Operating Temperature | -40°C ~ 105°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | OCP, OVP, SCP | Efficiency | 86% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 15V -15V 100mA, 100mA 9V - 36V Input | Current - Output (Max) | 100mA, 100mA |
| Applications | Medical |
