PA2718NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PA2718NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PA2718NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PA2718NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | XFMR FLYBACK CONV CONFIG T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.651 | $0.52 | $0.423 | $0.412 | $0.401 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.39 | $0.387 | $0.343 | $0.314 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PA2718NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | XFMR FLYBACK CONV CONFIG T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 72327 pcs | Data sheet | PA2718NL |
| Category | Transformers | Voltage - Primary | 85 ~ 256V |
| Voltage - Isolation | 3000Vrms | Voltage - Auxiliary | - |
| Type | Configurable (For DC/DC) | Size / Dimension | 0.531" L x 0.768" W (13.50mm x 19.50mm) |
| Series | - | Other Names | 553-2944 |
| Operating Temperature | -40°C ~ 130°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 11 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Intended Chipset | - |
| Inductance @ Frequency | - | Height - Seated (Max) | 0.591" (15.00mm) |
| Frequency | 132kHz | Footprint | 0.531" L x 0.768" W (13.50mm x 19.50mm) |
| Chipset Manufacturer | - | Applications | Flyback Converters |
