H1102FNL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy H1102FNL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy H1102FNL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | H1102FNL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | PULSE XFMR 1CT:1CT TX 1CT:1CT RX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.891 | $1.532 | $1.239 | $1.16 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.108 | $1.076 | $1.043 | $1.01 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | H1102FNL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | PULSE XFMR 1CT:1CT TX 1CT:1CT RX | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 35528 pcs | Data sheet | H1102FNL |
| Category | Transformers | Weight | - |
| Turns Ratio - Primary:Secondary | 1CT:1CT Transmitter, 1CT:1CT Receiver | Transformer Type | LAN 10G Base-T |
| Size / Dimension | 0.500" L x 0.358" W (12.70mm x 9.09mm) | Series | - |
| Other Names | 553-2196 | Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 13 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 350µH | Height - Seated (Max) | 0.236" (5.99mm) |
| Energy Time (E.T.) | - |
