HEV2AN-P-DC15V
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HEV2AN-P-DC15V with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HEV2AN-P-DC15V with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HEV2AN-P-DC15V |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE DPST 20A 15V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 50 pcs | ||||
|---|---|---|---|---|---|
| $29.21 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | HEV2AN-P-DC15V | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE DPST 20A 15V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1159 pcs | Data sheet | HE-V Series DatasheetHE-V Series New Prod Intro |
| Category | Relays | Turn On Voltage (Max) | 10.5 VDC |
| Turn Off Voltage (Min) | 0.75 VDC | Termination Style | PC Pin |
| Switching Voltage | 400VDC - Nom | Series | HE-V |
| Release Time | 10ms | Relay Type | General Purpose |
| Packaging | Bulk | Operating Temperature | -40°C ~ 55°C |
| Operate Time | 30ms | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 14 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Sealed - Flux Protection |
| Detailed Description | General Purpose Relay DPST-NO (2 Form A) 15VDC Coil Through Hole | Contact Rating (Current) | 20A |
| Contact Material | Silver Nickel (AgNi) | Contact Form | DPST-NO (2 Form A) |
| Coil Voltage | 15VDC | Coil Type | Non Latching |
| Coil Resistance | 117 Ohms | Coil Power | 1.92 W |
| Coil Current | 128mA |
