AN8016NSHE1V
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AN8016NSHE1V with confidence from Components-World.HK, 1 Year Warranty
Dowload AN8016NSHE1V Details in PDFSee Product Specifications for product details.
Buy AN8016NSHE1V with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AN8016NSHE1V |
|---|---|
| Manufacturer | Panasonic |
| Description | IC REG CTRLR BOOST 10-SSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | AN8016NSHE1V | Manufacturer | Panasonic |
|---|---|---|---|
| Description | IC REG CTRLR BOOST 10-SSOP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4165 pcs | Data sheet | AN8016NSH |
| Category | Integrated Circuits (ICs) | Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 14 V |
| Topology | Boost | Synchronous Rectifier | No |
| Supplier Device Package | 10-SSOP | Series | - |
| Serial Interfaces | - | Packaging | Tape & Reel (TR) |
| Package / Case | 10-FSOP (0.169", 4.30mm Width) | Output Type | Transistor Driver |
| Output Phases | 1 | Output Configuration | Positive |
| Other Names | AN8016NSHE1VTR | Operating Temperature | -30°C ~ 85°C (TA) |
| Number of Outputs | 1 | Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Function | Step-Up |
| Frequency - Switching | 2kHz ~ 1MHz | Duty Cycle (Max) | 80% |
| Detailed Description | Boost Regulator Positive Output Step-Up DC-DC Controller IC 10-SSOP | Control Features | Enable, Soft Start |
| Clock Sync | No | Base Part Number | AN8016NSH |
