Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - DC/DC & AC/DC (Off-Line) S > ISL8225MEVAL4Z

ISL8225MEVAL4Z

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ISL8225MEVAL4Z with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	ISL8225MEVAL4Z
Manufacturer	Intersil
Description	BOARD EVAL FOR ISL8225M
Lead Free Status / RoHS Status	Not applicable / Not applicable

~~In Stock~~ 1201 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	100 pcs
Reference Price (In US Dollars)	$34.791	$32.995	$29.853

Product parameter
Data sheet

Product parameter

Part Number	ISL8225MEVAL4Z	Manufacturer	Intersil
Description	BOARD EVAL FOR ISL8225M	Lead Free Status / RoHS Status	Not applicable / Not applicable
Quantity Available	1201 pcs	Data sheet	ISL8225M ISL8225MEVAL4Z Setup Procedure
Category	Development Boards, Kits, Programmers	Voltage - Output	1.2V, 1.5V
Voltage - Input	4.5 V ~ 20 V	Utilized IC / Part	ISL8225M
Supplied Contents	Board(s)	Series	-
Regulator Topology	Buck	Outputs and Type	2, Non-Isolated
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	13 Weeks
Main Purpose	DC/DC, Step Down	Lead Free Status / RoHS Status	Not applicable / Not applicable
Frequency - Switching	-	Detailed Description	ISL8225M - DC/DC, Step Down 2, Non-Isolated Outputs Evaluation Board
Current - Output	15A, 15A	Board Type	Fully Populated
