Home > Products > Circuit Protection > TVS - Diodes > SMBJ10CA/54

SMBJ10CA/54

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SMBJ10CA/54 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	SMBJ10CA/54
Manufacturer	Electro-Films (EFI) / Vishay
Description	TVS DIODE 10V 17V DO214AA
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 182868 pcs
Reference Price (In US Dollars)	750 pcs
Reference Price (In US Dollars)	$0.113

Product parameter
Data sheet

Product parameter

Part Number	SMBJ10CA/54	Manufacturer	Electro-Films (EFI) / Vishay
Description	TVS DIODE 10V 17V DO214AA	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	182868 pcs	Data sheet	SMBJ5.0A - SMBJ188A
Category	Circuit Protection	Voltage - Reverse Standoff (Typ)	10V
Voltage - Clamping (Max) @ Ipp	17V	Voltage - Breakdown (Min)	11.1V
Type	Zener	Supplier Device Package	DO-214AA (SMBJ)
Series	TransZorb®	Power Line Protection	No
Power - Peak Pulse	600W	Packaging	Tape & Reel (TR)
Package / Case	DO-214AA, SMB	Other Names	SMBJ10CA/1 SMBJ10CA/1GITR SMBJ10CA/1GITR-ND SMBJ10CA/54GITR SMBJ10CAGITR SMBJ10CAGITR-ND
Operating Temperature	-55°C ~ 150°C (TJ)	Mounting Type	Surface Mount
Manufacturer Standard Lead Time	49 Weeks	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Current - Peak Pulse (10/1000µs)	35.3A	Capacitance @ Frequency	-
Bidirectional Channels	1	Base Part Number	SMBJ
Applications	General Purpose
