B65671D0000R048
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B65671D0000R048 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy B65671D0000R048 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | B65671D0000R048 |
|---|---|
| Manufacturer | EPCOS |
| Description | FERRITE CORE P 4.9UH N48 2PCS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.477 | $1.266 | $0.95 | $0.923 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $0.818 | $0.765 | $0.712 | $0.659 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | B65671D0000R048 | Manufacturer | EPCOS |
|---|---|---|---|
| Description | FERRITE CORE P 4.9UH N48 2PCS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 45564 pcs | Data sheet | B65671/2/5/9 Datasheet |
| Category | Magnetics - Transformer, Inductor Components | Width | - |
| Tolerance | -20%, +30% | Supplier Device Package | P 26 x 16 |
| Series | B65671 | Other Names | 495-5162 B65671D R 48 B65671DR48 B65671DR48-ND |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Minimum Core Cross Section (Amin) mm² | 76.5 |
| Material | N48 | Manufacturer Standard Lead Time | 47 Weeks |
| Length | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Factor (Al) | 4.9µH | Height | 8.15mm |
| Gap | Ungapped | Finish | Uncoated |
| Effective Permeability (µe) | 1560 | Effective Magnetic Volume (Ve) mm³ | 3460 |
| Effective Length (le) mm | 37.2 | Effective Area (Ae) mm² | 93 |
| Diameter | 26.00mm | Core Type | P (Pot Core) |
| Core Factor (ΣI/A) mm1 | 0.4 |
