PC142AX
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PC142AX with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PC142AX with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PC142AX |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN JACK MONO 3.55MM PCB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.337 | $1.886 | $1.722 | $1.64 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $1.558 | $1.394 | $1.332 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | PC142AX | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN JACK MONO 3.55MM PCB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 24911 pcs | Data sheet | Jack Schematics |
| Category | Connectors, Interconnects | Voltage - Rated | 48VDC |
| Thread Size | - | Termination | Solder Eyelet(s) |
| Signal Lines | Mono | Shielding | Unshielded |
| Series | TINI-D-JAX® | Panel Hole Size | - |
| Packaging | Bulk | Other Names | PC142AX-ND SC2849 |
| Operating Temperature | - | Number of Positions/Contacts | 2 Conductors, 3 Contacts |
| Mounting Type | Through Hole | Mating Length/Depth | - |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Internal Switch(s) | Single Switch | Insulation Color | - |
| Industry Recognized Mating Diameter | 3.55mm (0.14", Tini Plug) | Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer |
| Housing Material | Plastic | Gender | Female |
| Features | - | Detailed Description | 3.55mm (0.14", Tini Plug) Phone Jack Mono Connector Solder Eyelet(s) |
| Current Rating | 250mA | Contact Material - Plating | Tin |
| Contact Material | Copper Alloy | Connector Type | Phone Jack |
| Cable Opening | - | Body Material | Copper Alloy |
| Body Color | Silver, Black | Actual Diameter | 0.145" (3.68mm) |
