1825136-7
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1825136-7 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1825136-7 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1825136-7 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | SWITCH TOGGLE SPDT 5A 120V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.275 | $2.162 | $2.105 | $2.048 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.991 | $1.877 | $1.593 | $1.507 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1825136-7 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | SWITCH TOGGLE SPDT 5A 120V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 25621 pcs | Data sheet | Switches Core Program Catalog1825136 Drawing |
| Category | Switches | Voltage Rating - DC | 28V |
| Voltage Rating - AC | 120V | Termination Style | Solder Lug |
| Switch Function | On-On | Series | Gemini A |
| Panel Cutout Dimensions | Circular - 6.35mm Dia | Packaging | Bulk |
| Other Names | 1825136-7-ND 450-2170 A101KZQ04 A101KZQ04-ND |
Operating Temperature | -30°C ~ 85°C |
| Mounting Type | Panel Mount | Manufacturer Standard Lead Time | 9 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Illumination Voltage (Nominal) | - | Illumination Type, Color | - |
| Illumination | Non-Illuminated | Features | Epoxy Sealed Terminals |
| Electrical Life | 6,000 Cycles | Detailed Description | Toggle Switch SPDT Panel Mount |
| Current Rating | 5A (AC/DC) | Circuit | SPDT |
| Bushing Thread | 1/4-40 | Actuator Type | Locking Lever |
| Actuator Material | Brass, Nickel Plated | Actuator Length | 16.51mm |
