1461792001
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1461792001 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1461792001 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1461792001 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | RX 2 COIL 1 LAYER 10.6UH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | |
|---|---|---|---|---|---|
| $4.402 | $4.166 | $3.452 | $3.166 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1461792001 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | RX 2 COIL 1 LAYER 10.6UH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 9400 pcs | Data sheet | 1461792001 Prod Spec1461792001 DrawingPowerLife™ Power Coils Brochure1461792001 Appl Spec |
| Category | Inductors, Coils, Chokes | Type | 2 Coil, 1 Layer |
| Tolerance | ±2% | Size / Dimension | 2.547" L x 2.110" W x 0.055" H (64.70mm x 53.60mm x 1.40mm) |
| Series | NuCurrent, PowerLife, 146179 | Q @ Freq | 24 @ 200kHz |
| Other Names | 146179-2001 WM15007 |
Operating Temperature | - |
| Manufacturer Standard Lead Time | 8 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 10.6µH | Function | Receiver |
| Frequency - Self Resonant | - | Detailed Description | 2 Coil, 1 Layer 10.6µH Wireless Charging Coil Receiver 190 mOhm |
| DC Resistance (DCR) | 190 mOhm | Current Rating | - |
| Current - Saturation | - |
