V5236BP-T
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy V5236BP-T with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy V5236BP-T with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | V5236BP-T |
|---|---|
| Manufacturer | ASSMANN WSW Components |
| Description | HEATSINK ANOD ALUM SOT-32/TO-220 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.326 | $0.309 | $0.294 | $0.286 | $0.282 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.263 | $0.248 | $0.224 | $0.217 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | V5236BP-T | Manufacturer | ASSMANN WSW Components |
|---|---|---|---|
| Description | HEATSINK ANOD ALUM SOT-32/TO-220 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 100086 pcs | Data sheet | V5236BP-T/SNP-T Drawing |
| Category | Fans, Thermal Management | Width | 1.000" (25.40mm) |
| Type | Board Level, Vertical | Thermal Resistance @ Natural | 18.00°C/W |
| Thermal Resistance @ Forced Air Flow | - | Shape | Rectangular, Fins |
| Series | - | Power Dissipation @ Temperature Rise | - |
| Package Cooled | SOT-32, TO-220 | Other Names | AE10810 V5236BPT |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 20 Weeks |
| Length | 1.189" (30.20mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.315" (8.00mm) | Diameter | - |
| Detailed Description | Heat Sink SOT-32, TO-220 Aluminum Board Level, Vertical | Attachment Method | Bolt On and Board Mounts |
