V5220L
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy V5220L with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy V5220L with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | V5220L |
|---|---|
| Manufacturer | ASSMANN WSW Components |
| Description | HEATSINK ALUM ANOD TO-220 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.409 | $0.387 | $0.377 | $0.366 | $0.346 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.326 | $0.305 | $0.285 | $0.275 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | V5220L | Manufacturer | ASSMANN WSW Components |
|---|---|---|---|
| Description | HEATSINK ALUM ANOD TO-220 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 75094 pcs | Data sheet | V5220L Drawing |
| Category | Fans, Thermal Management | Width | 1.260" (32.00mm) |
| Type | Board Level | Thermal Resistance @ Natural | 8.00°C/W |
| Thermal Resistance @ Forced Air Flow | - | Shape | Rectangular, Fins |
| Series | - | Power Dissipation @ Temperature Rise | - |
| Package Cooled | TO-220 | Other Names | AE10828 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 20 Weeks |
| Length | 1.181" (30.00mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.787" (19.99mm) | Diameter | - |
| Detailed Description | Heat Sink TO-220 Aluminum Board Level | Attachment Method | Bolt On |
