ES1DAF
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ES1DAF with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ES1DAF with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ES1DAF |
|---|---|
| Manufacturer | AMI Semiconductor / ON Semiconductor |
| Description | DIODE GEN PURP 200V 1A DO214AD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 10000 pcs | 30000 pcs | |||
|---|---|---|---|---|---|
| $0.038 | $0.035 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ES1DAF | Manufacturer | AMI Semiconductor / ON Semiconductor |
|---|---|---|---|
| Description | DIODE GEN PURP 200V 1A DO214AD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 638988 pcs | Data sheet | ES1DAF, ES1JAF |
| Category | Discrete Semiconductor Products | Voltage - Forward (Vf) (Max) @ If | 950mV @ 1A |
| Voltage - DC Reverse (Vr) (Max) | 200V | Supplier Device Package | DO-214AD (SMAF) |
| Speed | Fast Recovery = 200mA (Io) | Series | Automotive, AEC-Q101 |
| Reverse Recovery Time (trr) | 34ns | Packaging | Tape & Reel (TR) |
| Package / Case | DO-214AD, SMAF | Other Names | ES1DAFTR |
| Operating Temperature - Junction | -55°C ~ 150°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 17 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Diode Type | Standard |
| Detailed Description | Diode Standard 200V 1A Surface Mount DO-214AD (SMAF) | Current - Reverse Leakage @ Vr | 1µA @ 200V |
| Current - Average Rectified (Io) | 1A | Capacitance @ Vr, F | 15pF @ 4V, 1MHz |
